Precision Measuring Equipment
| Gear Tester | 3D Measuring Machine |
|---|---|
| Max. Ø2,500 mm dia. | Max. 3m(W) x 4m(L) x 2m(H) |
Quality Facilities
Metallurgical Testing Lab
| Mechanical Properties | Testing Equipment |
|---|---|
| Hardness | Micro-Vickers Hardness Tester |
| Rockwell Hardness Tester (C-Scale) | |
| Brinell Hardness Tester | |
| Microstructure | Optical Microscope (Min. x 50, Max. x 1,000) |
| Tensile Strength | Universal Testing Machine |
| Impact Strength | Charpy Impact Test Machine |
Reliability Test
-
1. Test Motor
-
2. Torque Meter RPM Sensor
-
3. Test Gearbox
-
4. Load Gearbox
-
5. Load Motor
| Test Scope |
ㆍPerformance and endurance tests for heavy construction equipment traveling reducer ㆍPerformance and endurance tests for heavy construction equipment transmission ㆍEndurance test for wind power turbine gearbox ㆍEndurance test for jack-up drive unit ㆍPerformance and endurance tests for various gearboxes |
|---|---|
| Test Items |
ㆍHeat Balance ㆍEndurance Test ㆍPerformance Test ㆍOver Load Test ㆍNoise / Vibration / Temperature / Torque & Speed |
| Previous Tests |
ㆍContinuous endurance test for 80 ton exacavator traveling reducer ㆍPerformance and endurance tests for 14 ton wheel exacavator transmission ㆍEndurance test for 200 ton crawler crane slewing reducer ㆍPerformance and endurance tests for 2.5MW wind power turbine yaw drive ㆍEndurance test for 30 ton deck crane gearbox ㆍEndurance test for 5MW wind power turbine pitch drive ㆍEndurance test for 5000 ton jack-up drive unit ㆍEndurance test for combine gearbox |
Non-Destructive Test
| Test Methods | Inspector Level |
|---|---|
| Radiographic Test | Level 3 |
| Ultrasonic Test | |
| Magnetic Particle Test | |
| Penetrant test |
